Air curtain WING E150 EC with inverter fan
Аir curtain WING E150 EC
It is equipped with a high power heater. It ensures safe operation without overloading the fan. The asymmetrical distribution of the heating helps to adjust the curtain to the client’s needs.
Main advantages of WIng air curtains
- The side cap, shaped like a diamond – not only protects the engine inlet, the cooling system, but also performs a visual function for a more beautiful and attractive appearance.
- The low-temperature heater ensures safe operation without overloading the fan. The asymmetrical distribution of the heating ensures the best adaptation of the air curtain to the individual requirements of the customers.
- Modern engine and fan designs save up to 60% of energy compared to conventional solutions.
- Double coating (galvanization + powder coating) – provides long-term protection against corrosion and consistent aesthetic qualities.
- Due to its optimized construction, cleaning the air curtain is convenient and does not require disassembly of any part. This guarantees high hygiene of the appliance and hassle-free operation.
The WING air curtains perfectly blend with the design of the room
Specifications
| Model | Water heating | Electric heating | No heating | |||||||
| WING W100 | WING W150 | WING W200 | WING E100 | WING E150 | WING E200 | WING C100 | WING C150 | WING C200 | ||
| EC | EC | EC | EC | EC | EC | EC | EC | EC | ||
| maximum door length (when installing 1 curtain) |
m | 1 | 1,5 | 2 | 1 | 1,5 | 2 | 1 | 1,5 | 2 |
| maximum door height (with horizontal installation of the curtain)** | m | 3,7 | 3,7 | 4 | ||||||
| maximum air flow rate *** | m3/h | 1850 | 3100 | 4400 | 1850 | 3150 | 4500 | 1950 | 3200 | 4600 |
| heating range * | kW | 4-17 | 10-32 | 17-47 | 2/6 or 4/6 | 4/12 or 8/12 | 6/15 or 9/15 | – | ||
| maximum fluid temperature | °C | 95 | – | – | ||||||
| maximum working pressure | MPa | 1,6 | – | – | ||||||
| volume of water | dm3 | 1,6 | 2,6 | 3,6 | – | – | ||||
| heat exchanger rows | pcs | 2 | – | – | ||||||
| power supply voltage | V/ph/Hz | ~ 230/1/50 | ~230/1/50 for 2kW ~ 400/3/50 for 2/4/6kW | ~400/3/50 | ~230/1/50 | |||||
| power of heaters | kW | – | 2 and 4 | 4 and 8 | 6 and 9 | – | ||||
| working current | A | – | 3/6/ max 9 | 6/11,3/ max 17,3 | 8,5/12,9/ max 21,4 | – | ||||
| fan power (EC motor) |
kW | 0,15 | 0,18 | 0,26 | 0,15 | 0,18 | 0,26 | 0,15 | 0,18 | 0,26 |
| operating current (EC motor) | A | 1,1 | 1,3 | 1,9 | 1,1 | 1,3 | 1,9 | 1,1 | 1,3 | 1,9 |
| weight (without water) EC motor | kg | 21,5 | 29 | 37,5 | 22 | 30,5 | 39 | 19 | 25,5 | 32,5 |
| protection class | IP | IP 20 | ||||||||
Note:
* Control configuration optional: Wing E100 2/6 kW or 4/6 kW, for Wing E150 4 / 12kW or 8 / 12kW, for Wing E200 6/15 kW or 9/15 kW
** Air flow rate depends on fan speed
*** measured at 3 m. distance from the curtain mounted horizontally on a wall
Special brackets and fixing points allow the curtain to be installed immediately.
