Air-to-water inverter heat pump Crystal ONYX PRO 8S
Inverter air-to-water heat pump, split system. Many applications in one system – Heating, cooling and DHW with just one system. DHW can also be used for underfloor heating, radiator heating and fan coil units.
Inverter heat pump Crystal ONYX PRO air-to-water type, split system
Many applications in one system
Heating, cooling and DHW with just one system. DHW can also be used for underfloor heating, radiator heating and fan coil units.
Environmental protection
Freon R32(HFC-32) with 0 ODP and 675GWP, low carbon content and no harm to the ozone layer.
Energy efficiency
ONYX PRO heat pumps use a renewable energy source. The use of renewable sources reduces energy dependence.
Wide operating range
- Cooling mode operation up to 46°C
- Heating mode operation down to -28°C
Control
- Full touchscreen color screen
- Easier management and monitoring
- Built-in WiFi module, TUYA app
- Temperature curve management
- Room temperature control
- Two temperature zones
- Control of additional sources
- Cascade control of up to 15 machines*
*after June 2025
Hydraulic module components
- Built-in electric heater 3 kW (6 kW option)
- New board with more inputs/outputs
- Electronic pump with speed selection
- Larger expansion tank – 8 L
Outdoor unit components
- Single-fan outdoor unit
- Mini VRF based
- GMCC twin-rotor compressor
- Refrigerant reinjection
- DC low-speed fans
- Combined circuit board with cooling from the refrigeration circuit
Dimensions
High efficiency at low outdoor temperature
Thanks to a highly efficient compressor, a large-area heat exchanger and a precise control system, the heat pump can maintain a high temperature, even at -10°C and -15°C.
Technical data
|
Outdoor unit |
PRO CLO-8S |
PRO CLO-10S |
PRO CLO-12S |
PRO CLO-16S |
||
|
Indoor unit |
PRO CLI-8S |
PRO CLI-10S |
PRO CLI-12S |
PRO CLI-16S |
||
|
Technical parameters |
||||||
|
Heating capacity/COP(A+7°C/W35°C) |
kW/COP |
8.00/5.05 |
10.00/4.80 |
12.10/4.80 |
16.00/4.50 |
|
|
Отоплителна мощност/COP(A+7°C/W55°C) |
kW/COP |
7.70/2.85 |
9.50/2.70 |
11.00/2.85 |
13.50/2.95 |
|
|
Heating capacity / COP (A-7 ° C / W35 ° C) |
kW/COP |
8.00/2.70 |
9.00/2.70 |
10.50/2.70 |
12.90/2.70 |
|
|
Heating capacity / COP (A-7 ° C / W55 ° C) |
kW/COP |
7.00/1.95 |
8.00/1.85 |
10.00/1.95 |
10.50/2.00 |
|
|
Heating capacity / COP (A-15 ° C / W35 ° C) |
kW/COP |
6.80/2.27 |
8.50/2.19 |
10.16/2.33 |
12.01/2.27 |
|
|
Heating capacity / COP (A-15 ° C / W55 ° C) |
kW/COP |
5.94/1.33 |
7.42/1.43 |
8.87/1.52 |
10.23/1.41 |
|
|
Cooling capacity / EER (A35 ° C / W7 ° C) |
kW/EER |
6.50/2.95 |
8.00/2.90 |
11.00/2.75 |
13.50/2.60 |
|
|
Cooling capacity / EER (A35 ° C / W18 ° C) |
kW/EER |
7.00/4.40 |
9.00/4.10 |
11.00/4.25 |
14.00/3.80 |
|
|
A+7°C; W35°C (ErP-temperate climate) |
Prated/SCOP |
kW/--- |
8.80/4.90 |
9.50/4.88 |
12.00/4.70 |
14.00/4.63 |
|
ηs 30°C/35°C |
% |
190% |
189% |
185% |
182% |
|
|
EE class 30°C/35°C |
--- |
A+++ |
A+++ |
A+++ |
A+++ |
|
|
A+7°C; W55°C (ErP-temperate climate) |
Prated/SCOP |
kW/--- |
7.50/3.30 |
9.00/3.27 |
11.60/3.32 |
13.00/3.40 |
|
ηs 47°C/55°C |
% |
129% |
128% |
130% |
133% |
|
|
EE class 47°C/55°C |
--- |
A++ |
A++ |
A++ |
A++ |
|
|
Hydraulic module |
||||||
|
Power supply |
V/Ph/Hz |
220-240/1/50 |
220-240/1/50 |
220-240/1/50 |
220-240/1/50 |
|
|
Power cable |
mm2 |
3×2.5 |
3×2.5 |
3×2.5 |
3×2.5 |
|
|
Communication cable (indoor-outdoor) |
mm2 |
2×0.75 (3x0.75) + shielding |
2×0.75 (3x0.75) + shielding |
2×0.75 + shielding |
2×0.75 + shielding |
|
|
Noise - power/pressure (1m) |
dB(A) (1) |
42/34 |
42/34 |
43/35 |
43/35 |
|
|
Dimensions (W * H * D) |
mm |
490*342*910 |
490*342*910 |
490*342*910 |
490*910*340 |
|
|
Packaging (W*H*D) |
mm |
620*425*1105 |
620*425*1105 |
620*425*1105 |
620*1105*425 |
|
|
Net / Gross weight |
kg |
59/64 |
59/64 |
61/66 |
61/66 |
|
|
Water connections (In. – Out.) |
mm/inch |
DN25/1’’ – DN25/1’’ |
DN25/1’’ – DN25/1’’ |
DN32/1 1/4’’ – DN32/1 1/4’’ |
DN32/1 1/4’’ – DN32/1 1/4’’ |
|
|
Water pump |
--- |
Electronic, 9 mH2O |
Electronic, 9 mH2O |
Electronic, 9 mH2O |
Electronic, 9 mH2O |
|
|
Expansion tank |
L |
8.0 |
8.0 |
8.0 |
8.0 |
|
|
Power of electric heater |
kW |
3.0 (6.0 - optional) |
3.0 (6.0 - optional) |
3.0 (6.0 - optional) |
3.0 (6.0 - optional) |
|
|
Maximum power power |
kW |
3.3 |
3.3 |
3.3 |
3.3 |
|
|
Maximum cons. current |
A |
16.0 |
16.0 |
16.0 |
16.0 |
|
|
Outdoor unit |
||||||
|
Power supply |
V/Ph/Hz |
220-240/1/50 |
220-240/1/50 |
380-400/3/50 |
380-400/3/50 |
|
|
Power cable |
mm2 |
3×4 |
3×4 |
5×2.5 |
5×2.5 |
|
|
Noise - power/pressure (1m) |
dB(A) (1) |
66/58 |
67/59 |
68/60 |
69/61 |
|
|
Maximum power power |
kW |
4.4 |
4.8 |
6.0 |
7.2 |
|
|
Maximum конс. current |
A |
20.0 |
22.0 |
9.0 |
11.0 |
|
|
Dimensions (W * H * D) |
mm |
1032*445*807 |
1032*445*807 |
1098*528*869 |
1098*528*869 |
|
|
Packing (W * H * D) |
mm |
1075*495*875 |
1075*495*875 |
1140*545*1010 |
1140*545*1010 |
|
|
Net / Gross weight |
kg |
67/73 |
71.5/77 |
100.1/115 |
103.3/117.1 |
|
|
Air flow |
m³/h |
4200 |
4200 |
5500 |
5500 |
|
|
Diameter of freon pipes |
mm |
9.52/15.88 |
9.52/15.88 |
9.52/15.88 |
9.52/15.88 |
|
|
Max. Pipe length / displacement |
m |
30/20 |
30/20 |
30/20 |
30/20 |
|
|
Refrigerant Agent |
Type / Quantity |
kg |
R32/1.7 |
R32/2.0 |
R32/2.0 |
R32/2.1 |
|
Recharge after 15 m |
g |
Total length of pipes – 15 m)*38 g/m |
||||
|
Operating outdoor temperature |
Cooling |
°C |
-5 ÷ 50°C |
|||
|
Heating |
°C |
-25 ÷ 43°C |
||||
|
DHW |
°C |
-25 ÷ 43°C |
||||
|
Water temperature in the installation |
Cooling |
°C |
+5 ÷ 25°C |
|||
|
Heating |
°C |
+25 ÷ 62°C |
||||
|
DHW |
°C |
+40 ÷ 62°C |
||||
