Air-to-water heat pump, monoblock Crystal LAVA, LAVA-09AM
Air-to-water heat pump, monoblock Crystal LAVA is not a luxury, but is what you need for your comfort. Functional solution for heating, cooling and DHW.
Air-to-water heat pump, monoblock Crystal LAVA
Why choose a heat pump Crystal Lava
The new series of heat pumps Crystal Lava impresses with many technical advantages. The design is completely different from all our other models. With its stylish body and excellent efficiency, Crystal Lava is a big step forward in heat pump technology. Intelligent power management reduces the number of switching cycles and extends compressor life by 20%. Many new technologies have been deployed to reduce the noise problem. In this product, all the details are perfectly made.
An air-to-water heat pump can deliver about 4 times more heat energy than the electricity it uses. This is possible due to the fact that the heat pump transfers heat instead of transforming it from some kind of fuel, as is the principle of standard heating systems.
Multiple applications
Crystal Lava can provide efficient heating and cooling for your home or commercial buildings, as well as DHW for everyday use. In this way, you economically and conveniently get multiple applications from one appliance.
Excellent performance
- High energy efficiency (A+++)
- Wide operating range (-25~43ºC)
- Quiet work
- Innovative compressor
Easy to use
- Easy control
- WiFi function
- Management of 2 temperatures
Easy installation and maintenance
- Monoblock system with all the necessary components in the kit
- Easy disassembly and assembly
- Changing the board in 10 minutes
Easy installation
1. Monoblock system
Thanks to the compact design, no large space is required for its installation. All hydraulic elements are included in the monoblock. No specialists are needed for the construction of freon routes.
2. Energy class A+++
Thanks to high-quality components and advanced technology, all heat pumps in the Crystal Lava range reach the A+++ energy class and meet the requirements for Erp certified by TUV.
 |
 |
Quiet work
3. Quiet mode of operation
Components providing low noise levels
- Quiet and high quality fan
- The DC inverter fan motor with rubber pads minimizes the noise level.
- Special anti-vibration support of the fan motor
- Compressor noise reduction chamber
- Sound insulation inside the entire housing.
Intelligent control
- Advanced compressor speed management minimizes the noise level while significantly extending its life.
4. Easy-to-use touch screen control
With a sleek design and clean interface, Crystal Lava’s operating panel ensures user-friendly use.
- Easy control
- WiFi function
- Heating curves
- Management of 2 temperatures
5. Wifi function
The built-in Wifi feature allows you to control the heat pump remotely and check the current data from the app on your phone.
Easy to use application with various functions
- On/Off
- Choice of operating mode
- Current temperature
- Set the desired temperature
6. Applications of Crystal Lava
The Crystal Lava heat pump can easily satisfy your heating, cooling and DHW needs.
7. Components
All-DC inverter technology
All moving components – the compressor, the water pump and the fan motor, are a type of DC inverter that improves the performance of the entire system and balances the power of the appliance and energy consumption in an intelligent way.
High Quality Evaporator
An inorganic coated evaporator can effectively prevent frost buildup, helping the system reduce energy loss for defrosting by 10%.
Safety
Sparkless electrical components ensure the safety of the system.
Easy maintenance
| DIMENSIONS (mm) | A | B | C | D | E | F | J | K | L | M | |
| MODEL | |||||||||||
| LAVA-06AM | 1014 | 697 | 379 | 406 | 690 | 420 | 440 | 329 | 121 | 141 | |
| LAVA-09AM | 1174 | 846 | 379 | 406 | 810 | 420 | 440 | 131 | 120 | 148 | |
| LAVA-12AM | 1174 | 846 | 379 | 406 | 810 | 420 | 440 | 131 | 120 | 148 | |
| LAVA-19AM | 1095 | 1438 | 403 | 440 | 610 | 425 | 445 | 166 | 887 | 96 | |
Technical data
| Model | LAVA-06AM | LAVA-09AM | LAVA-12AM | LAVA-19AM | ||
| IP protection | IPXX | IPX4 | IPX4 | IPX4 | IPX4 | |
| Electric power supply | ||||||
| Electric power supply – Outdoor unit | Outdoor unit | V / Hz / Ph | 230V/50Hz/1ph | 230V/50Hz/1ph | 230V/50Hz/1Ph | 230V/50Hz/1Ph |
| Technical parameters | ||||||
| Min./max heating power (1) | kW | 3.3~7.2 | 5.4~9.7 | 5.9~11.9 | 6.6~18.8 | |
| Min / max heating power (1) | KW | 0.7~1.6 | 1.2~2.4 | 1.3~2.9 | 1.3~4.6 | |
| C.O.P min/max (1) | W/W | 4.26~ 4.87 | 4.04~4.53 | 4.05~4.67 | 4.03~5.01 | |
| Min / max heating capacity (2) | kW | 3.1~6.9 | 5.1~8.8 | 6~11.5 | 6.1~18.4 | |
| Min / max heating power (2) | KW | 0.9~1.9 | 1.5~2.9 | 1.6~3.6 | 1.7~5.6 | |
| C.O.P min/max (2) | W/W | 3.41~3.78 | 3.03~3.4 | 3.19~3.66 | 3.29~3.71 | |
| SCOP – Temperate climate, low temperature | W | 4.66 | 4.61 | 4.62 | 4.62 | |
| Energy class | A+++ | A+++ | A+++ | A+++ | ||
| Min / max Cooling capacity (3) | kW | 3.1~7.1 | 4.2~9.1 | 5.1~11.3 | 5.5~19.2 | |
| Min / max cooling power (3) | KW | 0.82~1.9 | 1.28~2.5 | 1.34~3.4 | 1.3~5.0 | |
| E.E.R. min./max. (3) | W/W | 3.32~4.25 | 3.28~3.71 | 3.33~3.82 | 3.81~4.71 | |
| Min / max cooling capacity (4) (A35/W7) | kW | 1.8~4.8 | 3.8~7.5 | 4.2~8.1 | 4.7~13.1 | |
| Min / max cooling power (4) | KW | 0.66~2.54 | 1.6~2.7 | 1.6~3.1 | 1.5~4.6 | |
| E.E.R. min./max. (4) | W/W | 2.54~2.84 | 2.46~2.72 | 2.61~2.73 | 2.89~3.25 | |
| Min./ max. Operating outdoor temperature in heating mode | °C | -25~43 | -25~43 | -25~43 | -25~43 | |
| Maximum temp. Operating outdoor temperature in cooling mode | °C | 7~43 | 7~43 | 7~43 | 7~43 | |
| Maximum temp. in the installation in heating mode | °C | 60 | 60 | 60 | 60 | |
| Min. Pace. in the installation in heating mode | °C | 20 | 20 | 20 | 20 | |
| Min. Pace. in the installation in cooling mode | °C | 7 | 7 | 7 | 7 | |
| Noise level | Outdoor unit | dB (A) | 52 | 53 | 53 | 61 |
| Components | ||||||
| Fan | Debit | m³/h | 2500 | 3280 | 3280 | 6200 |
| Titanium Tube Heat Exchanger | Pressure drop | kPa | 22 | 22 | 26 | 30 |
| Water connections | Inch | 1” | 1” | 1” | 1-1/2” | |
| Freon | Type | / | R32 | R32 | R32 | R32 |
| Quantity | kg | 0.75 | 1.15 | 1.3kg | 2.9 | |
| Compressor | Type | / | Rotary | Rotary | Rotary | Rotary |
| Hydraulic connections | ||||||
| Mininmal water flow rate | m³/h | 0.5 | 0.8 | 1.03 | 1.64 | |
| Nominal water flow rate | m³/h | 1.0 | 1.6 | 2.06 | 3.27 | |
| Water connections | Inch | 1” | 1” | 1” | 1-1/4” | |
| Dimensions and weight | ||||||
| Dimensions (WxD x H) | Outdoor unit | mm | 1015x380x700 | 1175x380x845 | 1175x380x845 | 1095×405×1440 |
| Packaging (Wx D x H) | Outdoor unit | mm | 1080x470x865 | 1245x480x1020 | 1245x480x1020 | 1150×470×1580 |
| Net weight | Outdoor unit | kg | 70 | 79 | 82 | 138 |
| Gross weight | Outdoor unit | kg | 81 | 90 | 93 | 153 |
| Included in the kit | ||||||
| WiFI module | Yes / No | Yes | Yes | Yes | Yes | |
| Communication cable | m | 10 | 10 | 10 | 10 | |
